Traction Link DC
Traction Link DC© is a full digital drive suitable for driving Traction and DC servomotors with permanent magnets.
It works with ModBus RTU and CanOpen network commands. Its compact size incorporates a high construction technology that makes it particularly suitable for piloting servomotors in traction applications with battery power at 12-24-48V, where dynamic performance and remarkable regularity of operation are required.
Available functions:
- Single DC power supply
- Operating modes: CanOpen Ds402, Rs232 ModBus RTU
- 6 Diagnostic Leds (States and Alarms), 2 Leds CanOpen activity
- Serial feedback: Encoder
- Protected for short-circuit, min / max voltage, overtemperature, Ixt motor thermal image
- Current monitor signal
DOWNLOAD Documentation:
- Component certification UL/CSA (on request)
- Connections between Traction Link Dc and Microphase motors (on request)
All the used components are UL/CSA marked: the relative descriptive file is available.
